BIPAP MACHINE WITH ST MODE

Key Features:

• Operational Modes: CPAP, AUTO, Auto S, S, T, ST
• Superior Comfort: Excellent synchronization and user-friendly design for a restful experience
• Ultra-Quiet Performance: 22 dBA ultra-low noise, Sponge-free design for silence box, protect healthy breathing, Advanced noise-canceling technology, enjoy comfortable sleeping
• User data information showed on screen, Professional software to generate sleep reports
• Alarm: Various alarm prompts to protect the treatment effect of patients
• Integrated Humidification: Built-in humidifier and optional heated tubing maintain stable temperature and humidity. Stable temperature and humidity control
• Comprehensive Monitoring: Split-screen displays waveforms, parameters, and user data, with professional sleep reports
• Safety First: Various alarm prompts enhance treatment safety and effectiveness.
• Optional GPRS: Supports optional GPRS module for data transmission realize remote management.
• Connectivity Options: Optional bluetooth oximeter, Show SpO2 value on screen
• Hygienic Design: Sponge-free silence box ensures healthy breathing and easy maintenance.

Specification:

• Pressure range: 4-25cmH2O
• Work Mode: CPAP, AUTO, Auto S, S, T, ST
• Expiratory pressure: 4cmH2O~25cmH2O
• Inspiratory pressure: 4cmH2O~25cmH2O
• Tubing heating function: Yes
• Mobile network: Optional
• Data cloud platform: Optional
• Pressure rise/fall time: 100ms-900m
• Pressure difference: 2cmH2O~ 10cmH2O
• 1/E ratio: 10%-90%
• 1/E sensitivity: 5 Levels
• Backup rate: Sbpm-60bpm, step size 1 bpm, tolerance ± 1 bpm
• Target tidal volume: 200ml-1200ml, step size 10ml
• Ramp time: 0-60min
• Noise: : ≤22 dBA @10cmH2O
• Data storage: TF card, > 5 years
• Screen (inch): 3.5inch color display
• Heating tubing temperature: 10° C-30° C adjustable, step size 1 ° C
• Humidity level: Heating and humidification, level 1-5 adjustable
• Preheat: ON/OFF
• Flight mode: ON/OFF
• Alarm: Mask off, suffocation, pressure abnormality, tubing abnormality
• Bluetooth oximeter: Optional
• Power: Input: 100-240V~, 50/60Hz, 1.5AMax. Output: 24V= 3A
• Dimensions(cm): 26.68Lx17.25Wx11.85H(machine)
• Carton dimensions(cm): 41 L x 29W x 17.SH (1 pc/carton)
• Weight(with humidifier): 4.07Kg (1 pc/carton)
